| 1.Electrical Characteristics | |
| Rated voltage: | DC 5V |
| Resolution: | 16pulses/360° |
| Insulation resistance: | 10MΩ Min at DC 50V |
| Dielectric strength: | 1 minute at AC300V |
| Phase Difference: | 16≥5.0ms |
| 2.Mechanical Characteristics | |
| Total ratational angle: | 360°(Endless) |
| Detent torque: | 2±20mN.m.(20-200gf.cm) |
| Shaft wobble: | 1.0*L/30mm p-p Max(L:shaft length) |
| Push-Pull Strength of shaft | 10N |
| 3.Endurance Characteristics | |
| Rotational life: | 30,000cycles |
| Operating temperature range: | -20ºC to 80ºC |
| Storage temperature range: | -40ºC to+85ºC |
Application:
